Authorized Distributor since 2002 for Fluid Handling System.

Graco Official Website

Image Product Category for Graco

Sealant & Adhesive Equipment Products, Page : 1 of 4

iQ-T Dispense Valve

GRACO Sealant and Adhesive Equiptment, iQ-T.

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

More Info....

E-Flo SP Pump

GRACO Sealant and Adhesive Equiptment, Electric Pump, e-flo SP.

The E-Flo SP electric supply pump is designed for industrial and automotive sealant and adhesive application. This advanced pump will drastically increase efficiency, improve system control capabilities, optimise process performance, and provide critical performance data.

More Info....

Therm O-Flo 200

GRACO Sealant and Adhesive Equiptment, Therm-O-Flo 200

Therm O-Flo 200 is an industrial bulk hot melt system for hot melt sealants and adhesive in 200 liter (55 gal) pails. Capable of melt rates up to 11 lb/min (5 kg/min). It offers improved great production throughput, better process monitoring and reliable, efficient operation.

More Info....
GRACO Sealant and Adhesive Equiptment, Therm-O-Flo 200

iQ-T Dispense Valve Specification

  • Air Inlet Size (in) : 5/16
  • Air Inlet Thread Type : Push-to-Connect
  • Ambient/Warm Melt/Hot Melt : Ambient
  • Applicator Type : Tip-Seal
  • Component Type : Single Component
  • Fluid Inlet Size (in) : ¼
  • Fluid Inlet Thread Gender : Female
  • Fluid Inlet Thread Type : NPT
  • Gun Activation : Automatic
  • Maximum Air Pressure (MPa) : 0.83
  • Maximum Air Pressure (bar) : 8.3
  • Maximum Air Pressure (psi) : 120
  • Maximum Fluid Pressure (MPa) : 28
  • Maximum Fluid Pressure (bar) : 276
  • Maximum Fluid Pressure (psi) : 4000
  • Mount Location : Direct Mount Solenoid
  • Nozzle Size (mm) : 2.5
  • Outlet Block Length (mm) : 60
  • Solenoid Valve Voltage Rating (V DC) : 24
  • Weight (kg) : 1.1
